| 型號 | TE-350P | TE-650P | TE-1200P |
| 溫度範圍 | 環境溫度至350°C | 環境溫度至650°C | 50°C至1200°C |
| 內部參考精度 | ±0.1°C | ±0.1°C | ±2.20°C |
| 解析度 | 0.01°C | 0.01°C | 0.1°C |
| 穩定性 | ±0.05°C | ±0.05°C | ±0.1°C |
| 逕向均勻性 | ±0.05°C @ 50°C ±0.10°C @ 150°C ±0.15°C @ 350°C |
±0.10°C @ 50°C ±0.20°C @ 150°C ±0.40°C @ 650°C |
±0.15°C @ 50°C ±0.25°C @ 650°C ±0.25°C @ 1100°C |
| 軸向均勻性 TA-350P/TA650P(40mm) TA-1200P(20mm) |
±0.05°C @ 50°C ±0.10°C @ 150°C ±0.15°C @ 350°C |
±0.10°C @ 50°C ±0.20°C @ 300°C ±0.40°C @ 650°C |
±0.15°C @ 50°C ±0.25°C @ 650°C ±0.25°C @ 1100°C |
| 升溫時間 | 13min (50°C to 350°C) | 18min (50°C to 650°C) | 100min (100°C to 1200°C) |
| 降溫時間 | 12min (350°C to 100°C) | 22min (650°C to 100°C) | 5h (1200°C to 200°C) |
| 電源供應 | 500W | 1000W | 800W |
| 校正槽直徑x深度 | ø32mm x 124mm | ø32mm x 124mm | ø34mm x 130mm |
| 重量 | 8.0kg | 10.0kg | 12.6kg |
| 尺寸 (高 x 寬 x 深) | 260 x 180 x 270mm | 260 x 180 x 270mm | 350 x 180 x 270mm |
